Products

IPTV SET-TOP BOX MAG351/352

MAG351/352 is a premium IPTV/OTT Set-Top Box for operators, providing TV services via IP networks. Main advantage of the MAG351/352 is 4K standard support that will give your subscribers an opportunity to watch the video in the best quality. In turn, the 2 GB of RAM and Broadcom chipset with 10 000 DMIPS create extra velocity.

4K support; HEVC support; Super-power media processor with Broadcom chipset and 12 000 DMIPS productivity; 2 Gigabyte of RAM; In-built dual-band Wi-Fi 2.4GHz/5GHz(ac)(optional) and Bluetooth 4.0 adaptors;

IPTV/OTT Set-Top Box of Premium Class

Functions on Demand
MAG351/352 plays the latest audio and video formats and it supports subtitles, format and image settings, choice of audio track and work with the playlists.

Support of 4K
MAG351/352 can playback up-to-date video resolution UltraHD, giving the most realistic image.

Increased productivity
Larger RAM and powerful media processor by Broadcom allowed us to increase the velocity of STB.

Specifications

Dimensions
Width/depth/height, (mm) 175x132x42
Weight, g 190

Hardware
Chipset BCM7252s
Processor ARM A15 (B15) Dual Core CPU
Processor perfomance 12 000 DMIPS
RAM 2 Gb
Flash memory 8 Gb

Software
Operating system Linux 3.3, Android TV(optional)
Built-in Media Portal with WebKit-based IPTV-functionality HTTP 1.1, HTML 4.01 XHTML 1.0/1.1; DOM 1, 2, 3, CSS 1, 2, 3; XML 1.0, XSLT 1.0, XPath 1.0 ; SOAP 1.1; JavaScript ECMA-262, revision 5; Media JavaScript API; C layer SDK
DRM option Secure Media, Verimatrix
Middleware supported Ministra TV-platform, SoftAtHome

Interfaces
HDMI 2.0-output, HDMI 2.0-input, Composite + stereo A/V output, Audio output S/PDIF, Ethernet 1 Gb/s, 2*USB 3.0 (Wi-Fi adapter can be connected), SD slot, Built-in Wi-Fi 2.4 GHz/5 GHz ac (optional)
Sources of media content
PC and NAS in local network,Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices

Audio&Video
Audio codecs MPEG-1 layer I/II, MPEG-2 layer II, MPEG-2 layer III (mp3), Dolby Digital plus (optional), DTS (optional)
Audio formats MP3, MPA, M4A, WMA (optional), OGG, WAV
Video modes 1080i, 1080p, 720p, 576p, 480p, PAL, NTSC
Video codecs MPEG1/2 MP@HL, H.264 HP@level 4.1, H.265 (HEVC), MPEG4 part 2 (ASP), WMV-9 (optional), VC1 video, XviD; 3D and HD video supporting
Video containers MKV, MPEG-TS, MPEG-PS, M2TS, VOB, AVI, MOV, MP4, ASF, QT, WMV
Image formats JPEG, PNG, BMP, GIF, RAW
Subtitles DVB, SRT, text MKV
Playlist formats M3U

Standard set
MAG351/352 Set-Top Box, Mini jack cable to RCA (A/V), Remote control, 2 AAA batteries, packaging, Power adapter 12 V 1 A, User manual

The cost-effective solution for your IPTV/OTT project with a full set of functions. MAG324 is a basic set-top box on a Broadcom chipset that supports HEVC compression. The device, therefore, runs quickly and with minimal network load. Through its HDMI 1.4b output, you can enjoy high-quality video.

We have also completely changed the case and remote control design, making it more ergonomic and easier to use.

BCM75839, Linux 3.3, OpenGL ES 2.0, HEVC, 512 MB Flash/1 GB RAM

KEY FEATURES

• Broadcom chipset
• HEVC HD video decoding
• Increased memory (1 Gb RAM and 512 Mb Flash) for easy MW and
  UI applications integration
• 3D graphics engine (1 Gpix/s OpenGL ES 2.0)
• Best in class user experience in streaming of live
  video playback
• New small form-factor

Configuration Specification:

CPU
·Quad Cortex-A15

GPU
·GPU: Mali-400P2

Memory
·32-bit DDR3 (2GB)
·Flash: Nand Flash 8GB( Nand/EMMC 4GB,8GB,16GB,32GB Optional)(price is different)

Wi-Fi
·Built-in Wi-Fi 802.11 b/g/n

Network
.RJ45 Interface 10M/100M adaptive

Media Decoder:

Video Decoder:
.H.265 decoding up to 4K×2K/30fps
.H.264 HP/L5.1 up to 4K×2K/30fps

SVC, MVC, VC-1/WMV, AVS, WebM, RMVB, MPEG1/2/4, MJPEG, H.263, DivX 3/4/5, Xvid, Real Video, VP6/8

Format:

MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc.

Audio Decoder:

MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, Real Audio(AC-3 Optional )

Format:

MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc.

system

·OS:Android4.4,Linux system(Optional)
·Compatible with 3D. Microsoft Windows 8

IPTV Specification:

API

·JS Linux API Network (portal) protocol support.

Streaming

·RTSP, HTTP, HLS, RTMP, MMS, RTP, UDP, IGMP,

Vod

·RTSP, HTTP, HLS, RTMP, MMS, RTP, UDP, IGMP,

Remote Control

·Play,Stop,Fast forward, fast rewind,Forward, backward,Flying squirrels,learning,Etc.

Port

DC-In:DC-5V 2000ma( VDE,Xterra,BS)

USB:USB*2 HOST function

WIFI:Built-in wifi /outer wifi

RCA-AV:CVBS-1,Audio-L/R

RJ-45:100M Ethernet

HDTV:HDMI
